X ray Unit

Model No: MR-XR101D
Place of Origin: Zhejiang,China (Mainland)
Payment & Shipping Terms
Payment Term: T/T,L/C,WU
MOQ: 1 Set/Sets
Means of Transport: Ocean
Supply Capacity
Production Capacity: 2000sets per month
Packing: wood carton
Delivery Date: 10-30days
High Frequency Mobile X-ray Equipment(100mA)
Specifications
Power Output: 5.0KW
Frequency : 40KHZ
X-ray Tube : Fixed anode Focus : 1.5 Tube Voltage: 40~120KV (interval 1KV)
Tube Current: 40~49KV 100mA 1~180 mAs 50~59KV 77mA 1~140 mAs 60~69KV 64mA 1~125 mAs 70~79KV 55mA 1~110 mAs 80~89KV 49mA 1~100 mAs 90~99KV 44mA 1~80 mAs 100~109KV 32mA 1~63 mAs
110~120KV 25mA 1~50 mAs
MAs : 1.0~180 mAs (46 steps) Power Supply: 220V±10% 50Hz inner-resistance≤1.0Ω
Operation Method: Wire/Wireless control With a back-up battery
Packing Details : 1500mm×750mm×1850mm N.W. 270kgs G.W.355kgs
Feature:
1.New Molding Design,have all the aforesaid feature of the High-Frequency Mobile X-ray Equipment. More higher KV and mAs, more applicable scope and better film effect.
2.Rotary pillar,single arm support.
3.Rotary pillar can ±90 rotate, radiography location more easy and fast.
4.Internally installed High Performance Large capacity charge battery, once charge can take about 200 photoes.
5.The height is 2 meters, the machine is the lightest,smallest and easy moved and use in the same kind machines.

High Frequency Mobile X-ray Equipment(100mA) has been presented above, want more similar products, please click X-ray Equipment.
